Double Fuse 220V 10A IEC Inlet Plug In RFI Filter For Medical Equipment

Double Fuse 220V 10A IEC Inlet Plug In RFI Filter For Medical Equipment

IEC inlet filters YB-C series:

• Rated currents up to 10A
• Single or dural-fuse holder
• 2-pole socket switch
• Optional medical version(R5 type)
• Compact design with optimal shielding
• Approvals:

Electrical schematic:

                         Standard type

                            R5 type

Product Features:

1. Screw-on mounting from the front side
2. (R5) types comply with the requirements of IEC/EN60601-1 for safety clearance, leakage current, and hi-pot testing.
3. There are a variety of parts and combinations to meet different customer's EMC tests
4. Customized products according to customer's requirements

Typical Applications:

Rule of Nomination:

YB   12    C2     -10A     -Q         (R    5          G)                   C1---Single fuse

          |      |          |          |             |      |           |

  circuit  case  current output  option  option  option             C2---Dual fuse

Tabulates:

Model No.

Rated Current @40°C

Terminal         Options

Bleeder resistor(optional)

Ground inductance G(optional)

Leakage current 250V/50Hz

Electrical Schematic

Rated Voltage(V)

Operating Frequency(Hz)

YB12C1-1A

1A

Q

S

-

-

-

<0.8mA

Fig.1

115/250V

50/60Hz

YB12C1-3A

3A

Q

S

-

-

-

Fig.1

YB12C1-6A

6A

Q

S

-

-

-

Fig.1

YB12C1-8A

8A

Q

S

-

-

-

Fig.1

YB12C1-10A

10A

Q

S

-

-

-

Fig.1

YB12C2-1A

1A

Q

S

-

-

-

Fig.1

YB12C2-3A

3A

Q

S

-

-

-

Fig.1

YB12C2-6A

6A

Q

S

-

-

-

Fig.1

YB12C2-8A

8A

Q

S

-

-

-

Fig.1

YB12C2-10A

10A

Q

S

-

-

-

Fig.1

Medical Type:

Model No.

Rated Current @40°C

Terminal Options

Bleeder resistor(optional)R(MΩ)

Medical equipment 5

Ground inductance G(optional)

Leakage current 250V/50Hz

Electrical Schematic

Rated Voltage(V)

Operating Frequency(Hz)

YB12C2-1A-x(R5)

1A

Q

S

-

1

5

-

<5μA

Fig.2

115/250V

50/60Hz

YB12C2-3A-x(R5)

3A

Q

S

-

1

5

-

Fig.2

YB12C2-6A-x(R5)

6A

Q

S

-

1

5

-

Fig.2

YB12C2-8A-x(R5)

8A

Q

S

-

1

5

-

Fig.2

YB12C2-10A-x(R5)

10A

Q

S

-

1

5

-

Fig.2

Mechanical Dimension:(Unit: mm)

                                   C Case

Insertion loss table(In 50ohm system according to IEC/CISPR No.17):

                              3A                                                            6A                                                            10A

Sample

-- Sample Fee: Negotiate

-- Sample Time: 3~5 days

Payment

---Payment terms: Western Union, D/P, T/T,L/C

---Please remember to leave the correct contact information for delivery.

Packaging

Power Line Filter: CTN/300pcs

N/G W.: 13.5/14.3KG

Measures:0.565*0.285*0.225m

Shipment

---Shipping terms: DHL, UPS, FEDEX, TNT, EMS

---Port is Shenzhen or as requests.
